Technical Overview
Frameset
Frame:
Fourstroke Carbon | APS Suspension System | 100mm Travel | Fully Guided Internal Cable Routing | Post Mount Disc | 12 x 148mm Boost Thru-Axle
Fork:
RockShox SID SL Select+ | 100mm Travel
Suspension
Front Suspension:
RockShox SID SL Select+
Rear Suspension:
RockShox SIDLUXE
Remote Lockout:
RockShox TwistLoc 3P
Cockpit
Stem:
BMC MSM 01
Handlebar:
BMC MFB 01 Carbon | 760mm
Seat
Seatpost:
Bikeyoke Divine
Saddle:
Fizik Antares R7
Drivetrain
Crankset:
SRAM GX Eagle
Chainrings:
34T
Cassette:
SRAM XS-1275 Eagle Transmission (CS-XS-1275-A1)
Cassette Size:
10-52T
Chain:
SRAM GX Eagle Transmission Flattop
Rear Derailleur:
SRAM GX Eagle Transmission
Shifters:
SRAM AXS Pod Controller
Gears:
1 x 12
Bottom Bracket:
PF92 Bottom Bracket
Brakes
Brake Levers / Calipers:
SRAM Level TLM
Rotors:
SRAM Centerline Rotors
Rotor Size (F/R):
160 / 160 S-M | 180 / 160 L-XL
Wheels
Rims:
XCD-30W Carbon | 30mm Inner Width
Hubs (F/R):
XCD-30W
Tires:
Vittoria Mezcal | 2.35"
Tubeless Information:
Tubeless Ready Rims | Tubetype Tires
Additional Information
Tire Clearance:
62mm measured tire
Weight without Pedals:
11.40 kg | Size M
ASTM Classification:
Level 3
System Weight Limit:
110kg
General Product Safety Regulation (GPSR):
Safety Instructions GPSR (EU)
Responsible person according to GPSR (EU)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <172 | 172-182 | 180-188 | >188 |
| Reach | 437 | 457 | 477 | 500 |
| Stack | 584 | 592 | 600 | 615 |
| Bar Rise | 4 | 4 | 4 | 4 |
| Bar Sweep | 8° | 8° | 8° | 8° |
| Bar Width | 760 | 760 | 760 | 760 |
| BB Drop | 53 | 53 | 53 | 53 |
| Crank Length | 165 | 170 | 170 | 170 |
| Fork Length | 513 | 513 | 513 | 513 |
| Fork Rake | 44 | 44 | 44 | 44 |
| Front Center | 714 | 738 | 762 | 791 |
| Head Tube | 84 | 93 | 101 | 118 |
| Head Tube Angle | 66.75° | 66.75° | 66.75° | 66.75° |
| Rear Center | 432 | 432 | 432 | 432 |
| Seat Angle | 75.6° | 75.6° | 75.6° | 75.6° |
| Seat Tube | 420 | 430 | 460 | 490 |
| Seatpost Drop | 80 | 80 | 100 | 100 |
| Seatpost Length | 420 | 420 | 420 | 420 |
| Seatpost Offset | 0 | 0 | 0 | 0 |
| Standover Height | 725 | 725 | 725 | 765 |
| Stem Angle | -5° | -5° | -5° | -5° |
| Stem Length | 50 | 60 | 60 | 70 |
| Top Tube | 574 | 597 | 621 | 649 |
| Trail | 113 | 113 | 113 | 113 |
| Wheelbase | 1139 | 1171 | 1188 | 1218 |
