Name: URS AL ONE
Brand: BMC
SKU: 30001396
Price: 2599.0 USD
Availability: OutOfStock

Color: Orange
Año modelo: 2022

Producto archivado BMC

[{"id":40929277706319,"title":"XS","option1":"XS","option2":null,"option3":null,"sku":"30001396","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"URS AL ONE - XS","public_title":"XS","options":["XS"],"price":259900,"weight":15,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027871487","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929277739087,"title":"S","option1":"S","option2":null,"option3":null,"sku":"30001397","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"URS AL ONE - S","public_title":"S","options":["S"],"price":259900,"weight":15,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027871579","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929277804623,"title":"M","option1":"M","option2":null,"option3":null,"sku":"30001398","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"URS AL ONE - M","public_title":"M","options":["M"],"price":259900,"weight":15,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027871661","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929277837391,"title":"L","option1":"L","option2":null,"option3":null,"sku":"30001399","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"URS AL ONE - L","public_title":"L","options":["L"],"price":259900,"weight":15,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027871654","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40929277870159,"title":"XL","option1":"XL","option2":null,"option3":null,"sku":"30001400","requires_shipping":true,"taxable":true,"featured_image":null,"available":false,"name":"URS AL ONE - XL","public_title":"XL","options":["XL"],"price":259900,"weight":15,"compare_at_price":null,"inventory_quantity":0,"inventory_management":"shopify","inventory_policy":"deny","barcode":"7630027871647","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Descripción técnica

Cuadro

Cockpit

Potencia:
BMC MSM 02

Manillar:
BMC RAB 03 | Ergo Top Shape | Compact Bend

Seat

Tija de Sillín:
BMC RSP 03

Sillín:
Selle Royal

Transmisión

Platos y Bielas:
SRAM Apex 1

Platos:
40T

Cassette:
SRAM Apex

Tamaño del cassette:
11-42T

Cadena:
SRAM Apex

Cambio Trasero:
SRAM APEX 1 Long Cage

Manetas de Cambio:
SRAM Apex 1 HRD

Marchas:
1 x 11

Pedalier:
PF86 Bottom Bracket

Frenos

Pinzas de Freno:
SRAM Apex HRD

Discos:
SRAM Centerline

Tamaño del disco:
180 / 160mm

Ruedas

Llantas:
DT Swiss C1850 SPLINE | 23mm

Bujes:
DT Swiss C1850 SPLINE

Neumáticos:
WTB Riddler | 45mm

Información adicional

Paso de rueda:
45mm measured tire

Clasificación ASTM:
Level 2

Límite de peso del sistema:
120kg

Reglamento relativo a la seguridad general de los productos (GPSR):
Instrucciones de seguridad GPSR (UE)
Persona responsable según el GPSR (UE)

Size	XS	S	M	L	XL
Rider Height	< 165	162-172	170-182	180-192	>190
Reach	390	400	410	420	430
Stack	525	550	580	610	640
Bar Drop	130	130	130	130	130
Bar Reach	70	70	70	70	70
Bar Width	420	420	420	440	440
BB Drop	69	69	69	69	69
Crank Length	170	170	172.5	172.5	175
Fork Length	410	410	410	410	410
Fork Rake	45	45	45	45	45
Front Center	608	626	647	668	689
Head Tube	92	118	150	182	214
Head Tube Angle	70	70	70	70	70
Rear Center	430	430	430	430	430
Seat Angle	74	74	74	74	74
Seat Tube	430	445	475	505	540
Seatpost Length	350	350	350	350	350
Seatpost Offset	15	15	15	15	15
Standover Height	720	738	768	797	830
Stem Angle	±6	±6	±6	±6	±6
Stem Length	70	70	70	80	80
Top Tube	540	558	576	595	614
Trail	78	78	78	78	78
Wheelbase	1028	1047	1068	1089	1110

ICS Technical Manual
