Aperçu technique
Kit cadre
Cadre:
URS 01 Premium Carbon with Micro Travel Technology | Tuned Compliance Concept Gravel | Gravel+ Geometry | ICS Technology | Stalth Cable Routing | Fender and Rack Mounts | Flat Mount Disc | 12 x 142mm Thru-Axle
Fourche:
URS 01 Premium Carbon with Tuned Compliance Concept Gravel | ICS Technology Integrated BRake & Hub Dynamo Routing | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Suspension
Suspension Arrière:
Micro Travel Technology Stays
Cockpit
Potence:
ICS MTT x Redshift Suspension Stem | Integrated Cockpit System Technology
Cintre:
Easton EA70 AX
Seat
Tige de Selle:
URS 01 Premium Carbon D-Shaped Seatpost
Selle:
WTB SL8 Cromoly | Medium
Transmission
Pédalier:
Campagnolo Ekar
Plateaux:
Campagnolo Ekarrings
Cassette:
Campagnolo Ekar
Taille de cassette:
10-44T
Chaîne:
Campagnolo Ekar
Dérailleur Arrière:
Campagnolo Ekar
Leviers de Vitesses:
Campagnolo Ekar Ergopower
Vitesses:
1 x 13
Boîtier de pédalier:
PF86 Bottom Bracket
Freins
Leviers de Frein / Étriers:
Campagnolo Ekar
Disques:
Campagnolo Ekar AFS
Largeur de Pedalier:
160 / 160mm
Roues
Jantes:
Campagnolo Levante | 2-Way Fit | 30mm
Moyeux:
Campagnolo Levante
Pneus:
WTB Raddler | 40mm
Informations supplémentaires
Espace pour les pneus:
42mm measured tire
Classification ASTM:
Level 2
Limite de poids du système:
120kg
Règlement relatif à la sécurité générale des produits (GPSR):
Consignes de sécurité GPSR (UE)
Personne responsable conformément au GPSR (UE)
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | <170 | 172-180 | 178-188 | 186-196 |
| Reach | 403 | 415 | 419 | 429 |
| Stack | 538 | 569 | 603 | 641 |
| Bar Drop | 120 | 120 | 120 | 120 |
| Bar Reach | 80 | 80 | 80 | 80 |
| Bar Width | 420 | 420 | 440 | 440 |
| BB Drop | 69 | 69 | 69 | 69 |
| Crank Length | 170 | 172.5 | 172.5 | 175 |
| Fork Length | 407 | 407 | 407 | 407 |
| Fork Rake | 45 | 45 | 45 | 45 |
| Front Center | 625 | 648 | 665 | 700 |
| Head Tube | 113 | 146 | 172 | 207 |
| Head Tube Angle | 70 | 70 | 70 | 70 |
| Rear Center | 425 | 425 | 425 | 425 |
| Seat Angle | 74 | 74 | 74 | 74 |
| Seat Tube | 431 | 459 | 492 | 527 |
| Seatpost Length | 330 | 380 | 430 | 430 |
| Standover Height | 748 | 778 | 810 | 846 |
| Stem Angle | 0 | 0 | 0 | 0 |
| Stem Length | 70 | 70 | 80 | 90 |
| Top Tube | 557 | 578 | 591 | 612 |
| Trail | 77 | 77 | 77 | 77 |
| Wheelbase | 1041 | 1064 | 1081 | 1105 |
